Product Overview
The Huawei DBU50B is the battery unit of Huawei’s blade site power family, created for the one-site-one-blade approach that replaces equipment rooms with compact pole- or wall-mounted hardware. The unit stores energy for -48 VDC telecom loads and delivers up to 3 kW of backup power for macro and small-cell sites.
With a slim 300 x 120 x 420 mm blade format and approximately 26 kg weight, the DBU50B mounts on existing poles or walls without new civil works, enabling one-hour deployments. IP65 sealing and a fanless, bionic heat-dissipation design allow outdoor operation with no fan maintenance visits.
Two 80 A battery branches provide flexible backup distribution within the blade power architecture, complementing Huawei DPU DC units in complete site solutions. For operators densifying 5G networks, the DBU50B standardizes backup power across thousands of street-level sites while keeping OPEX low.
Key Features
- Blade-format battery backup unit for pole/wall-mounted sites
- 3 kW rated backup power at -48 VDC
- IP65 protection with fanless natural (bionic) heat dissipation
- Compact 300 x 120 x 420 mm footprint, approx. 26 kg, 1-hour deployment
- 2 x 80 A battery branches within the blade power architecture
- Part of Huawei one-site-one-blade site power solution
Specifications
| Parameter | Value |
|---|---|
| Capacity | 3 kW rated backup power; battery branches 2 x 80 A |
| Voltage | -48 VDC input system (battery unit in blade power architecture) |
| Dimensions | 300 mm (W) x 120 mm (D) x 420 mm (H) |
| Weight | approx. 26 kg |
| Protection | IP65 |
| Other | Fanless natural cooling; designed for wall/pole mounting using existing infrastructure; pairs with Huawei DPU blade DC units |
Key Features of DBU50B Blade Battery
DBU50B Blade Battery is part of the 48 V DC power system family widely used in telecom and data applications. Systems of this class commonly combine rectifier modules, monitoring controllers and distribution units in rack or cabinet formats.
Typical Applications of DBU50B Blade Battery
DC power systems of this type are widely used in telecom equipment rooms, base station sites, data centers and industrial control environments that require reliable -48 V DC power.
Selecting DBU50B Blade Battery with BS Comtec
BS Comtec supplies DC power systems and rectifier modules from Vertiv, Huawei, ZTE, Eltek and other brands with global delivery. Tell us your load budget, battery requirements and installation space for a tailored proposal.
Frequently Asked Questions
How do I size DBU50B Blade Battery for my site?
Start from your steady-state and peak DC load, redundancy requirements (N+1 or 2N), battery backup time and expansion plans. BS Comtec can model these figures and propose a suitable configuration.
Can DBU50B Blade Battery work with my existing rectifiers or batteries?
It depends on voltage range, communication protocols and mechanical compatibility. Provide your current system details and BS Comtec will review interfaces and recommend a compatible combination.
How is DBU50B Blade Battery shipped and delivered?
Systems and modules are packed for international freight, and lead times vary by model and destination. Contact BS Comtec for current availability, shipping options and delivery schedules.
What warranty and support come with DBU50B Blade Battery?
Warranty follows the manufacturer’s policy for the ordered configuration. BS Comtec assists with commissioning guidance, spare module supply and service coordination where required.
Where is DBU50B Blade Battery typically deployed?
It is commonly deployed in telecom central offices, outdoor cabinets, data centers and industrial facilities that rely on stable -48 V DC distribution.
