Product Overview
The Vertiv NetSure 211 is designed for all types of access applications in fixed and wireless networks, offering unmatched site installation flexibility in a compact -48 VDC package. The series provides 0.5 to 6 kW of power conversion (40-120 A) with an advanced control unit, up to six positions for 1000 W high-efficiency eSure rectifiers and integrated distribution options.
Two models are available: a 1RU shelf supporting up to three 1000 W rectifiers (3000 W in 23-inch racks, 2000 W in 19-inch) and a 2RU shelf supporting up to six rectifiers (6000 W in 23-inch, 4000 W in 19-inch). Single or dual AC feeds are available at 120 VAC or 220/240 VAC, giving integrators flexibility for shelter, cabinet and building installations.
Rectifiers operate from -40C to +75C and still provide 600 W at +65C, supported by an extremely wide 85-300 VAC input window. The Ethernet-accessible controller offers SNMP and RS232 interfaces for remote monitoring, battery test and charge management. Distribution options include battery disconnect breakers, load breakers and GMT fuses up to 15 A, and the system is designed for NEBS Level 3 compliance and UL listing.
Key Features
- Compact -48 VDC embedded power system, 0.5-6 kW / 40-120 A
- 1RU (3 x 1000 W) and 2RU (6 x 1000 W) shelf models for 19/23-inch racks
- eSure rectifiers operate -40 to +75C with 600 W output at +65C
- Wide 85-300 VAC input window with 120 VAC or 220/240 VAC feeds
- Ethernet, SNMP and RS232 remote monitoring with battery management
- Designed for NEBS Level 3 compliance and UL listed
Specifications
| Parameter | Value |
|---|---|
| Capacity | 0.5-6 kW (40-120 A), up to 6 x 1000 W eSure rectifiers |
| Voltage | -48 VDC output; single-phase 120 VAC or 208-240 VAC input; rectifier AC window 85-300 VAC |
| Dimensions | 1.75-5.25 in H x 19 or 23 in W x 12.4 in D |
| Weight | up to 39 lbs (approx. 17.7 kg) |
| Operating Temperature | Rectifiers -40 to +75C (600 W output to +65C) |
| Efficiency | Greater than 92% |
| Protection | Battery disconnect breakers, load breakers, GMT fuses up to 15 A; NEBS Level 3 design; UL listed |
| Other | 1RU and 2RU integrated distribution shelves; Ethernet/SNMP/RS232 controller; configuration-file based installation |
