Product Overview
The NetSure 212 is Vertiv’s compact embedded DC power system for small telecom equipment sites, access nodes and transmission gear that require reliable -48 VDC power in minimal space. The official C23 configuration delivers 1-2 kW (21-42 A) of rectified capacity with an ultra-slim subrack only 44 mm high.
The system accepts 200-250 VAC single-phase input and distributes -48 VDC to loads through integrated disconnects, fitting standard 19-inch racks at just 482.6 mm width and 290 mm depth. At approximately 10 kg or less, the NetSure 212 C23 is easy to install in cabinets, wall boxes and shallow enclosures typical of access networks.
As part of the Vertiv NetSure embedded family, the 212 shares control philosophy and spare parts strategy with larger NetSure systems, simplifying multi-site operations. It is positioned by Vertiv for indoor telecom power where footprint, acoustics and energy efficiency matter more than raw capacity.
Key Features
- Compact embedded -48 VDC system, 1-2 kW / 21-42 A
- Ultra-slim 44 mm (1U-class) subrack for 19-inch racks
- 200-250 VAC single-phase input
- Approximately 10 kg system weight for easy cabinet installation
- Shares NetSure family control and service ecosystem
- Designed for access network and compact telecom sites
Specifications
| Parameter | Value |
|---|---|
| Capacity | 1-2 kW (21-42 A) |
| Voltage | -48 VDC output; 200-250 VAC input |
| Dimensions | Subrack 44 x 482.6 x 290 mm (H x W x D) |
| Weight | 10 kg or less |
Key Features of NetSure 212 C23
NetSure 212 C23 is part of the 48 V DC power system family widely used in telecom and data applications. Systems of this class commonly combine rectifier modules, monitoring controllers and distribution units in rack or cabinet formats.
Typical Applications of NetSure 212 C23
DC power systems of this type are widely used in telecom equipment rooms, base station sites, data centers and industrial control environments that require reliable -48 V DC power.
Selecting NetSure 212 C23 with BS Comtec
BS Comtec supplies DC power systems and rectifier modules from Vertiv, Huawei, ZTE, Eltek and other brands with global delivery. Tell us your load budget, battery requirements and installation space for a tailored proposal.
Frequently Asked Questions
How do I size NetSure 212 C23 for my site?
Start from your steady-state and peak DC load, redundancy requirements (N+1 or 2N), battery backup time and expansion plans. BS Comtec can model these figures and propose a suitable configuration.
Can NetSure 212 C23 work with my existing rectifiers or batteries?
It depends on voltage range, communication protocols and mechanical compatibility. Provide your current system details and BS Comtec will review interfaces and recommend a compatible combination.
How is NetSure 212 C23 shipped and delivered?
Systems and modules are packed for international freight, and lead times vary by model and destination. Contact BS Comtec for current availability, shipping options and delivery schedules.
What warranty and support come with NetSure 212 C23?
Warranty follows the manufacturer’s policy for the ordered configuration. BS Comtec assists with commissioning guidance, spare module supply and service coordination where required.
Where is NetSure 212 C23 typically deployed?
It is commonly deployed in telecom central offices, outdoor cabinets, data centers and industrial facilities that rely on stable -48 V DC distribution.
What are the key specifications of NetSure 2100 A31-S1?
NetSure 2100 A31-S1 key specs: -48 VDC; 3 kW rectifier capacity (3 × 1000 W), 2 kW max load; Rectifier peak efficiency 95.4%; 1U subrack, fits 300 mm shallow cabinets. Full datasheet and test report available from BS Comtec on request.
Does BS Comtec supply NetSure 2100 A31-S1?
Yes. BS Comtec supplies NetSure 2100 A31-S1 (Vertiv line) from Singapore stock, MOQ from 1 piece; in-stock items dispatch within 24-48 hours with worldwide shipping.
Is there a cross-reference or equivalent for NetSure 2100 A31-S1?
BS Comtec maintains a cross-reference chart covering Huawei, Vertiv (Emerson), Eltek, ZTE and Delta 48V modules. Contact us for the direct equivalent of NetSure 2100 A31-S1.
